iKAN-124A Single-Row LED Message Display, 24 ASCII Characters, Modbus TCP
Single-row industrial LED message display with 24 ASCII characters, seven colours and web configuration. Supports Modbus TCP, EtherNet/IP and MQTT for PLC and IIoT integration.
- 24 ASCII or 12 Unicode characters on a single row, seven display colours
- 128 common messages with user-defined priority levels
- Text and up to 168 variables can be combined within one message
- Remote control from PLC, PC or smartphone via Modbus, Modbus TLS, MQTT, EtherNet/IP and Redfish
- Direct connection to DL/CL series sensor modules for real-time monitoring data
- Built-in real time clock and web-based configuration
13 217,84 kr per st.
| 1–9 st. | 13 217,84 kr | |
|---|---|---|
| 10–30 st. | 12 818,98 kr | −3 % |
| 31+ st. | 12 553,07 kr | −5 % |
Produktinformation "iKAN-124A Single-Row LED Message Display, 24 ASCII Characters, Modbus TCP"
iKAN-124A is a single-row LED message display for PLC-driven signage and status indication. It shows up to 24 ASCII or 12 Unicode characters in one of seven colours, and it can be configured through a web-based interface from a PC, smartphone or tablet over HTTPS.
Messages are held in a pool of 128 common messages, each with a user-defined priority. A single message can combine fixed text with up to 168 variables, so live PLC values can be displayed alongside static wording. The display also connects directly to DL/CL series sensor modules and has a built-in real time clock.
The series supports Modbus, Modbus TLS, MQTT, EtherNet/IP and Redfish, which allows integration with PLC, HMI and SCADA systems as well as cloud and IT/OT platforms. The module is not RoHS compliant and is listed under WEEE. Operating range is 0 ~ +60°C, and the aluminium-cased unit is designed for wall mounting.
Applications
- PLC HMI message display of real-time process data
- Indoor air quality display of CO, CO2, PM2.5, temperature and humidity from ICP DAS DL sensor modules
| Product type: | LED message display |
|---|---|
| Interface: | 2 × RJ-45, 2 × RS-485 |
| Protocol: | Modbus TCP |
| Ports: | 2 × RJ-45, 2 × RS-485 |
| Power input: | DC 5 V |
| Operating temperature: | 0 ~ +60 °C |
| Mounting: | Wall mounting |
| Housing: | Aluminum |
Specifikationer
| Display | |
|---|---|
| Size | iKAN-116A: Row: 1，ASCII Characters: 16，Unicode Characters: 8 iKAN-124A: Row: 1，ASCII Characters: 24，Unicode Characters: 12 |
| Real Time Clock | Date and time, 24 hour format including second, minute, hour, date, day of the week, month, year |
| Character Sets | 16 x 16 Unicode or 8 x 16 ASCII |
| Color | Red, Blue, Yellow, Green, Light Blue, Purple or White |
| Data Pool | 40 Coil values, 64 Float values, and 64 Integer values |
| Message Pool | 128 common messages with user-defined priority levels, Up to 20 Unicode characters or 50 ASCII characters each * For complex characters such as Thai, Hindi, or Arabic, please contact our sales team. |
| Ethernet | |
| Ports | 2 × RJ-45, 10/100 Base-TX, Switch Ports |
| Protocol | Modbus Master/Slave, Modbus TCP Master/Slave, GCI, HTTP/HTTPS, MQTT, EtherNet/IP and Redfish |
| Configuration | Web-based User Interface |
| COM Ports | |
| Ports | 2 × RS-485 |
| Baud Rate | 1200, 2400, 4800, 9600, 19200, 38400, 57600, 115200 |
| Data Format | N81, E81, O81 |
| Protocol | Modbus RTU Master/Slave |
| Power | |
| Input Range | DC 5V |
| Consumption | iKAN-116A: Typical (Normal Display): 6 A @ DC 5 V (30 W) Max. (Full Brightness): 20 A @ DC 5 V (100 W) iKAN-124A: Typical (Normal Display): 9 A @ DC 5 V (45 W) Max. (Full Brightness): 30 A @ DC 5 V (150 W) * Actual current consumption depends on display content and brightness settings. |
| Mechanical | |
| Casing | Aluminum |
| Dimensions (mm) | iKAN-116A: 1347 x 160 x 73 (W x L x H) iKAN-124A: 1987 x 160 x 73 (W x L x H) |
| Installation | Wall mounting |
| Weight | iKAN-116A: 4 Kg iKAN-124A: 4.6 Kg |
| Environment | |
| Operating Temperature | 0 ~ +60°C |
| Storage Temperature | -10 ~ +75°C |
| Humidity | 10 ~ 90% RH, Non-condensing |
Specifikationer enligt tillverkaren. Ändringar förbehålls.
