DLW-1120 Mini Weather Station, RS-485 and PoE Ethernet Output
Compact outdoor weather station measuring wind, pressure, illuminance, precipitation, temperature, humidity and PM1/PM2.5/PM10, with RS-485 and PoE Ethernet communication.
- Measures wind speed, wind direction, pressure, sea level, illuminance, precipitation, temperature, humidity and PM1/PM2.5/PM10
- RS-485 port with Modbus RTU and Ethernet port with Modbus TCP and MQTT
- PoE (IEEE 802.3af, Class 1) or +12 to +48 VDC terminal block power
- Real-time clock and data logger on board
- Alarm notifications via integration with the WISE controller
- Four-channel Form A (SPST) PhotoMOS relay output rated 100 VDC @ 1 A
36 063,77 kr per st.
| 1–9 st. | 36 063,77 kr | |
|---|---|---|
| 10–30 st. | 34 977,98 kr | −3 % |
| 31+ st. | 34 257,81 kr | −5 % |
Produktinformation "DLW-1120 Mini Weather Station, RS-485 and PoE Ethernet Output"
DLW-1120 CR is a mini weather station for monitoring outdoor conditions and airborne particulates in a single unit. It measures wind speed and direction, atmospheric pressure, sea level, illuminance, precipitation, temperature and humidity, along with PM1, PM2.5 and PM10 concentrations, making it suited to engineers who need local environmental data fed into a wider monitoring system.
The unit offers an RS-485 port running Modbus RTU and a 10/100 Base-TX Ethernet port that supports PoE, with Modbus TCP and MQTT available over Ethernet. Data can be logged on the device, and it can be integrated with the WISE controller to set alarm notifications for the monitored parameters. The housing is rated IP54 and can be fitted with a U-bolt or to a wall.
Typical use cases include greenhouse and agricultural monitoring, outdoor data collection at ports and marine sites, and remote stations where weather and particulate readings must be reported to a central control system.
Applications
- Outdoor weather monitoring
- Smart greenhouse and agricultural environmental monitoring
- Port and marine air quality and weather data collection
- Remote multi-station data collection and reporting
| Product type: | Weather station |
|---|---|
| Interface: | Ethernet, RS-485 |
| Protocol: | Modbus RTU, Modbus TCP, MQTT |
| Relay outputs: | Form Ax4, SPST, 100 VDC @ 1 A |
| Ports: | 1 x RS-485, 1 x RJ-45 |
| PoE: | IEEE 802.3af, Class 1 |
| Power input: | PoE or +12 to +48 VDC |
| Operating temperature: | -20 ~ +50 °C |
| Mounting: | U-bolt, wall |
Specifikationer
| CPU Module | |
|---|---|
| Watchdog Timer | Yes, Module, Communication (Programmable) |
| LED Indicators | |
| Status | PWR: Green for normal Operation Link: Green for the Ethernet-linked Alarm: Red for an alarm condition |
| System | |
| Alarm | Weather Monitoring (Wind Speed, Wind Direction, Pressure, Illuminance, Sea Level, RH/T, Precipitation), Particulates, Gas Monitoring (PM2.5) |
| Real Time Clock | Yes |
| Data Logger | Yes |
| Relay Output | PhotoMOS Relay, Form Ax4, SPST 100VDC @ 1A |
| Temperature Measurement | |
| Range | -40 ~ +80℃ |
| Resolution | 0.1℃ |
| Accuracy | ±0.5℃ |
| Humidity Measurement | |
| Range | 0 ~ 100% |
| Resolution | 0.1% |
| Accuracy | ±5% |
| Life Time | 10 years |
| Illuminance Measurement | |
| Range | 0 ~ 200,000 Lux |
| Resolution | 1 Lux |
| Accuracy | ± 5% |
| PM1/PM2.5/PM10 Measurement | |
| Range | 0 ~ 1000 μg/m3 |
| Resolution | 1 μg/m3 |
| Accuracy | ±10% |
| Response Time | 1 seconds |
| Warm-up Time | 20 seconds |
| Life Time | 5 years |
| Sea Level | |
| Range | -50 ~ 9000 m |
| Resolution | 0.1 m |
| Atmospheric Pressure | |
| Range | 300 ~ 1200 hPa |
| Accuracy | 1 hPa |
| Resolution | 0.1 hPa |
| Precipitation | |
| Range | 0 ~ 100 mm/hr |
| Accuracy | ± 10% |
| Resolution | 0.01 mm/hr |
| Wind Speed | |
| Rnge | 0 ~ 40 m/s |
| Accuracy | 5% |
| Resolution | 0.01 m/s |
| Wind Direction | |
| Range | 0 ~ 359° |
| Accuracy | <3° |
| Resolution | 1° |
| Ethernet | |
| Ports | 10/100 Base-TX, 8-Pin RJ-45 x1 |
| Access Control | Password and IP Filter |
| Protocol | Modbus TCP and MQTT |
| COM Ports | |
| Ports | 1 x RS-485 |
| Baud Rate | 1200 ~ 115200 bps |
| Protocol | Modbus RTU |
| Power | |
| Consumption | PoE: 1.10 W Max Non-PoE: 0.88 W Max |
| Powered from PoE | IEEE 802.3af, Class 1 (48 V) |
| Powered from Terminal Block | +12 to +48 VDC |
| Mechanical | |
| Dimensions (mm) | 288 x 122 x 389 (W x L x H) |
| Installation | U-bolt or Wall Mounting |
| Ingress Protection Rating | IP54 |
| Weight | 2.45 KG |
| Environment | |
| Operating Temperature | -20 to +50°C |
| Storage Temperature | -30 to +75°C |
| Humidity | 10% to 90% RH, Non-condensing |
Specifikationer enligt tillverkaren. Ändringar förbehålls.
