iSN-703-F1-L015 Triaxial MEMS Vibration Accelerometer, ±18g Range
Triaxial MEMS accelerometer with ±18g range, 400mV/g sensitivity per axis and 10Hz to 1kHz frequency response, supplied with a 1.5m cable for vibration analysis.
- Triaxial design measuring vibration on three orthogonal axes simultaneously
- ±18g amplitude range with 400mV/g sensitivity per axis
- Frequency response from 10Hz to 1kHz
- 3-wire voltage output with MEMS sensor type
- Bias voltage 10±0.5VDC; input range 22 to 26VDC, 3mA
- IP67 ingress protection rating
4 389,23 kr per st.
| 1–9 st. | 4 389,23 kr | |
|---|---|---|
| 10–30 st. | 4 256,56 kr | −3 % |
| 31+ st. | 4 168,11 kr | −5 % |
Produktinformation "iSN-703-F1-L015 Triaxial MEMS Vibration Accelerometer, ±18g Range"
The iSN-703-F1-L015 CR is a triaxial accelerometer that measures vibration on three orthogonal axes at the same time, so one sensor can cover the full vibration profile of a machine or structure. Its MEMS element and 3-wire voltage output make it a practical choice for engineers who need a compact sensor for vibration analysis.
Each axis offers a measuring range of ±18g and a sensitivity of 400mV/g, with a frequency response from 10Hz to 1kHz. The sensor has a bias voltage of 10±0.5VDC and runs from a 22 to 26VDC supply, drawing 3mA.
The housing is rated IP67 and measures (15±0.05) x (21±0.05) x (8.5±0.05) mm (W x L x H). This ordering code includes a 1.5m (150 cm) cable and is RoHS compliant.
Applications
- Vibration analysis
| Product type: | Triaxial accelerometer |
|---|---|
| Power input: | 22 ~ 26 VDC |
Specifikationer
| Vibration Measurement | |
|---|---|
| Axes | 3 |
| Sensor Type | MEMS |
| Amplitude Range | ±18g |
| Frequency Range | 10Hz~1KHz |
| Sensitivity | 400mV/g per axis |
| Bais Voltage | 10±0.5VDC |
| Power | |
| Input Range | 22~26VDC,3mA |
| Mechanical | |
| Dimensions (mm) | (15±0.05) x (21±0.05) x (8.5±0.05) (W x L x H) |
| Ingress Protection Rating | IP67 |
| Cable | |
| Length | 1.5m |
Specifikationer enligt tillverkaren. Ändringar förbehålls.
