ANT-15 15 dBi 2.4 GHz Omni-directional Dipole Antenna, RP-SMA
A 15 dBi dipole antenna for the 2.4 to 2.5 GHz band, supplied with a 1 m cable and an RP-SMA male plug for wireless links.
- 15 dBi gain for 2.4 to 2.5 GHz operation
- Omni-directional dipole antenna type
- 1 m cable with RP-SMA male plug connector
- Operating temperature range of -20°C to 60°C
- Antenna body dimensions φ35 x 1600 mm, weight 1050 g (antenna body only)
- RoHS and WEEE certified
2 808,22 kr per st.
| 1–9 st. | 2 808,22 kr | |
|---|---|---|
| 10–30 st. | 2 719,78 kr | −3 % |
| 31+ st. | 2 664,50 kr | −5 % |
Produktinformation "ANT-15 15 dBi 2.4 GHz Omni-directional Dipole Antenna, RP-SMA"
The ANT-15 CR is a 15 dBi omni-directional dipole antenna for 2.4 GHz wireless links. It is fitted with a 1 m cable terminated in an RP-SMA male plug, so it can be connected directly to a compatible wireless device with an RP-SMA female socket.
Choose this model when you need 15 dBi gain across the 2.4 to 2.5 GHz band and a cable run of 1 m. The antenna body measures φ35 x 1600 mm and weighs 1050 g, and it is rated for an operating temperature of -20°C to 60°C.
- Supplied with RoHS and WEEE certification
Applications
- 2.4 GHz wireless communication links
| Product type: | Antenna |
|---|---|
| Interface: | RP-SMA Male |
| Operating temperature: | -20 ~ +60 °C |
Specifikationer
| Mechanical | |
|---|---|
| Dimensions (mm) | φ35 x 1600 mm (Only Antenna Body) |
| Weight | 1050 g (Only Antenna Body) |
| Environment | |
| Operating Temperature | -20°C ~ 60°C |
| Antenna | |
| Type | Dipole |
| Connector | RP SMA Male (Plug) |
| Gain (dBi) | 15 |
| Band | 2.4 ~ 2.5GHz |
Specifikationer enligt tillverkaren. Ändringar förbehålls.
